Ayub Aluminium is a top manufacturer of Aluminium 2014 Square Bars, providing high-performance bars for aerospace, military, and structural applications across Saudi Arabia. Aluminium 2014 is a heat-treatable, copper-based alloy. It offers excellent strength, machinability, and wear resistance. Ayub Aluminium produces square bars to precise tolerances in various tempers and lengths. This ensures they are suitable for high-load and high-performance assemblies. With modern manufacturing capabilities and a focus on quality, Ayub Aluminium supports a range of technical industries.
Aluminium 2014 includes 4.4% copper, 0.8% manganese, 0.5% magnesium, and traces of silicon and iron. It is a high-strength alloy, providing tensile strength of 430 to 470 MPa and yield strength around 370 to 390 MPa in T6 temper. Elongation is about 10 to 12%. The density is 2.80 g/cm³. It has good fatigue resistance and excellent machinability, but its corrosion resistance is moderate, requiring surface treatment in harsh environments.
Specification : ASTM B 221 ASME SB 221, B211, B565, B316 1100, AMS 4102
Standard : ASTM, BS and all International Standards
Temper : O, H12, H14, H16, H18, H22, H24, H26, H32, H112
Length : 100 mm To 3000 mm Long & Above
Size : 5 mm To 500 mm
| Aluminium 2014 | Fe | Si | Mg | Mn | Cu | Zn | Ti | Al |
| 0.7 | 0.50 – 1.20 | 0.2 – 0.8 | 0.4 – 1.2 | 3.9 – 5.0 | 0.25 | 0.15 | 93.5 |
| Material | Temper | Diameter (mm) | Tensile Strength min ((N/mm²) | Yield Strength (min) (N/mm²) | Elongation on 5.65 V (min) |
| 2014 Bar | T4 | <20 | 370 | 230 | 11 |
| 2014 Bar | T4 | 20-75 | 390 | 250 | 11 |
| 2014 Bar | T4 | 75-150 | 390 | 250 | 9 |
| 2014 Bar | T4 | 150-200 | 370 | 230 | 8 |
| 2014 Bar | T6510 | 20-75 | 480 | 435 | 7 |
| 2014 Bar | T6510 | 75-150 | 465 | 420 | 7 |
| 2014 Bar | T6510 | 150-200 | 435 | 390 | 7 |
Density : 2.8 g/cm3
Melting point : 510°C (950°F)
Tensile Strength : 414 MPa – 60000 psi
| STANDARD | UNS | WERKSTOFF NR. | European Standard | BS (OLD) | ISO | USA (AA) | GERMANY (DIN) | IS | Canadian |
| Aluminium 2014 | A92014 | 3.1255 | EN AW-2014 | HE15 | AlCu4SiMg | 2014 | AlCuSiMn | 24345 | B26S |
Ayub Aluminium based in Riyadh, Saudi Arabia is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminum 2014 Square Bars to meet specific project needs. Our team at Ayub Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@ayubaluminium.com
These square bars are used in high-strength components like aircraft fittings, truck frames, missile parts, machine shafts, and precision tools. Their square shape is ideal for assemblies that require uniform load-bearing. Aluminium 2014 Square Bars are also in automotive parts, structural beams, and mechanical linkages. Their strength and wear resistance make them suitable for fasteners and gears in challenging mechanical environments.
