Ayub Aluminium stands out as a trusted manufacturer and supplier of Aluminium 6063 Square Bars in Riyadh, Saudi Arabia. We take pride in offering top-notch aluminium profiles that are built for strength, resist corrosion, and boast a fantastic finish. Aluminium 6063 is a medium-strength alloy known for its exceptional extrusion properties, good machinability, and the ability to achieve high-quality anodized finishes, making it perfect for both architectural and structural uses. Our square bars are crafted with precision, ensuring they have uniform dimensions, straightness, and smooth surfaces that meet the needs of engineering, fabrication, and decorative industries. Available in a variety of sizes and custom specifications, our Aluminium 6063 Square Bars from Ayub Aluminium promise reliable performance, visual appeal, and long-lasting durability for projects throughout Saudi Arabia and beyond.
These square bars are primarily made of aluminium, magnesium, and silicon, with a few trace elements added to boost mechanical strength, corrosion resistance, and surface quality. This alloy provides good tensile and yield strength while remaining lightweight and easy to work with. Its excellent anodizing properties allow for both protective and decorative finishes, and its non-magnetic, recyclable nature supports safe, sustainable, and eco-friendly engineering solutions.
Specification : ASTM B 221 ASME SB 221, B211, B565, B316 1100, AMS 4102
Standard : ASTM, BS and all International Standards
Temper : O, H12, H14, H16, H18, H22, H24, H26, H32, H112
Length : 100 mm To 3000 mm Long & Above
Size : 5 mm To 500 mm
| Aluminium 6063 | Fe | Si | Mg | Mn | Cu | Zn | Ti | Al |
| 0.35 | 0.20 – 0.60 | 0.45 – 0.90 | 0.10 | 0.10 | 0.10 | 0.10 | 97.5 |
| Temper | Tensile | Hardness | ||||
|---|---|---|---|---|---|---|
| Ultimate | Yield | Elongation | Brinell | |||
| KSI | MPA | KSI | MPA | % | ||
| T5, T52 | 27 | 186 | 21 | 145 | 12 | 60 |
| T6 | 35 | 241 | 31 | 214 | 12 | 73 |
Density : 2.70 g/cm³
Melting point : 600 °C
Tensile Strength : 130 Max MPa
Proof Stress : 160 Min MPa
| STANDARD | UNS | WERKSTOFF NR. | European Standard | BS(OLD) | ISO | USA (AA) |
| Aluminium 6063 | A96063 | 3.32206 | AW-AlMg1SiCu/EN AW-6063 | HE20 | AlMg1SiCu | AA6063 |
Aluminium 6063 Square Bars find their place in a variety of applications, including architectural frameworks, decorative trims, window frames, doors, railings, furniture, and transport components. They are perfect for industries that need lightweight, corrosion-resistant materials with a superior surface finish, suitable for both indoor and outdoor settings. In fabrication and engineering, these bars are essential components for machine parts, supports, and precision assemblies. Whether you need them for structural reinforcement, aesthetic design, or custom-engineered products, Aluminium 6063 Square Bars offer versatility and reliability.
Yes, we offer custom sizes for Aluminum 6063 Square Bars to meet specific project needs. Our team at Ayub Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@ayubaluminium.com
Aluminum 6063 square bars are versatile and widely used in various industries due to their excellent properties. Commonly used in the construction industry, they are ideal for window frames, doors and facades due to their aesthetics, corrosion resistance and mechanical flexibility in the construction industry they are used for structural supports, roof gutters and balustrades. These triangular wires are also used in the automotive industry for products such as bumpers, trims, brackets, and in addition to their light weight and high strength. Additionally, they find applications in electrical fittings, furniture, and decorative items.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
