Ayub Aluminium is a well-known manufacturer and supplier of Aluminium 3003 Flat Bars in Saudi Arabia. They offer corrosion-resistant and easily formable aluminium products for a variety of general-purpose applications. Aluminium 3003 is a non-heat-treatable alloy with excellent workability and moderate strength, making it ideal for roofing, cladding, and household equipment. Ayub Aluminium provides custom-cut flat bars for projects that require lightweight and durable materials.
Aluminium 3003 consists of about 1.2% manganese and the rest aluminium, along with small amounts of copper and iron. It boasts a tensile strength of 130 to 200 MPa and a yield strength of 115 MPa. The density is 2.73 g/cm³. It cannot be heat-treated but has good elongation (10 to 20%) and corrosion resistance, particularly in humid or mildly acidic environments. It is also suitable for anodizing and surface finishing.
Standards : ASTM B221, B211, B565, B316, AMS 4121 3003
Temper : O,H12,H14,H16,H18,H19,H22,H24,H26,H28,H32,H34,H36,H38
Standard : ASTM, ASME, AMS, GB/T, JIS
Length : 100 mm To 3000 mm Long & Above, Random, Fix & Cut Length or as per clients’ requirement
Size : 5 mm To 500 mm
Finish : Bright, Polish & Black
Type : Hot-Rolled (HR) / Cold-Rolled (CR) Sheet
| Alloy | Fe | Si | Mg | Mn | Cu | Zn | Ti | AI | ||||||||
| 3003 | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | 98.6 | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 0.30 | 0.70 | 0.20 | 0.40 | 0.01 | 0.05 | 1.0 | 1.5 | 0.05 | 0.20 | 0.01 | 0.10 | 0.020 | 0.030 | |||
| Alloy | UTS(Mpa) | % Elongation | |||
| Min | Max | 0.5 mm -0.8 mm | 0.81 mm – 1.30 mm | 1.30 mm – above | |
| 3003 | 95 | 135 | 20 | 23 | 24 |
| 115 | 160 | 6 | 7 | 8 | |
| 140 | 180 | 4 | 4 | 5 | |
| 165 | 205 | 3 | 3 | 4 | |
| 180 | — | 2 | 2 | 3 | |
| European Standard | GERMANY | UNS | WERKSTOFF NR. |
| AW-AlCu4Mg1 | AlCuMg2 | A93003 | 3.0517 |
Ayub Aluminium based in Riyadh, Saudi Arabia is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 3003 Flat Bars to meet specific project needs. Our team at Ayub Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@ayubaluminium.com
Our team is ready to assist you. Contact us for any queries or personalized solutions.
