Ayub Aluminium is a reliable producer and supplier of Aluminium 5754 Flat Bars in Riyadh, Saudi Arabia, with high-quality products engineered for resilience and performance. Aluminium 5754 is well known to have superior corrosion resistance, particularly in marine and industrial atmospheres. Our Aluminium 5754 Flat Bars are made to precise standards to suit international requirements and are suitable for heavy-duty structural and fabrication requirements. Prioritizing reliability, timely delivery, and competitive prices, Ayub Aluminium has emerged as an industry choice for industries seeking reliable aluminium flat bar solutions.
Aluminium 5754 Flat Bars consist predominantly of aluminium with magnesium as the main alloying element, with additions of manganese, silicon, and iron in small quantities to increase strength and resistance to corrosion. They have good mechanical properties with tensile strength in the range 220–330 MPa and yield strength in the range 80–240 MPa with high elongation and toughness. These flat bars have superior resistance to seawater and industrial contaminants, guaranteeing durability under harsh conditions and with good formability and machinability for various applications.
Standards : ASTM B221, B211, B565, B316, AMS 4121 5754
Temper :O,H12,H14,H16,H18,H19,H22,H24,H26,H28,H32,H34,H36,H38,H111,H112,H114,H 116,H321
Standard : ASTM, ASME, AMS, GB/T, JIS
Length : 100 mm To 3000 mm Long & Above, Random, Fix & Cut Length or as per clients’ requirement
Size : 5 mm To 500 mm
Finish : Bright, Polish & Black
Type : Hot-Rolled (HR) / Cold-Rolled (CR) Sheet
| Alloy | Mg | Mn | Si | Cu | Fe | Cr | Zn | Ti | Cu | Other | AI | |||||||||||
| 5754 | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | balance | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2.60 | 3.60 | 0.0 | 0.50 | 0.0 | 0.40 | 0.0 | 0.40 | 0.0 | 0.30 | 0.0 | 0.20 | 0.0 | 0.15 | 0.0 | 0.10 | 0.0 | 0.05 | 0.0 | 0.15 | |||
| Alloy | Temper | Thermal conductivity | Coefficient of thermal expansion | Melting point | Elastic modulus | Electrical conductivity | |
|---|---|---|---|---|---|---|---|
| W/m*K | µm/(m*K) | Min | Max | KN/mm2 | %IACS | ||
| 5754 | H22 | 132 | 23,7 | 595 | 645 | 70 | 32,5 |
| 132 | 23,7 | 595 | 645 | 70 | 32,5 | ||
| 132 | 23,7 | 595 | 645 | 70 | 32,5 | ||
| 132 | 23,7 | 595 | 645 | 70 | 32,5 | ||
| 23,7 | 595 | 645 | 70 | ||||
| 132 | 23,7 | 595 | 645 | 70 | 32,5 | ||
| European Standard | GERMANY | UNS | WERKSTOFF NR. |
| AW-AlMg2.5 | Al-Mg.2 | A95754 | 3.3535 |
Ayub Aluminium based in Riyadh, Saudi Arabia is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 5754 Flat Bars to meet specific project needs. Our team at Ayub Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@ayubaluminium.com
Aluminium 5754 Flat Bars are widely utilized in various industries due to their strength, corrosion resistance, and formability. They are used extensively in the marine industry for ship construction, flooring, tanks, and coastal works because of their seawater resistance. The automotive sector uses them in car panels, chassis parts, and fuel tanks. They are also commonly used in construction for skeletons, architectural uses, and industrial machinery. They are also applied in food processing and chemical applications where corrosion resistance and cleanliness are important, thus making Aluminium 5754 Flat Bars a multi-purpose engineering material.
